Light source

High-intensity red LED

Aimer

Red linear collimator

Image Frame

Maximum 60fps

Code support

1D

All the standard 1D barcode

2D

DataMatrix(ECC200), QR code , Micro QR, PDF417, MicroPDF417, Aztec etc.

Rotate

Omnidirectional barcoding reading

Accuracy

1D：3.3mil

2D：5.0mil

Standard Range for Typical Symbols

HD

SR

3.3mil Code 39

40mm ~  80mm

/

10mil Code 39

50mm ~ 150mm

50mm ~ 200mm

10mil Datamatrix

30mm ~ 130mm

35mm ~ 250mm

ENA-13 100%

30mm ~ 165mm

30mm ~ 300mm

Field of view

46° horizontal, 29° vertical

Trigger mode

Manual Trigger、Presentation Mode、Continuous Trigger Mode、Serial Port Command

Print Contrast

≥30%

Communication interface

USB、RS-232

Dimension

40mm x 50.3mm x 23mm

Weight

About 34g

Operating Temperature

0℃ to 50℃

Storage Temperature

-20℃ to 70℃

Humidity

5% to 95% RH non-condensing

Environmental Sealing

IP54

Shell material

Aluminium alloy+ABS

Power

DC 5V±5% ; 300 mA ±5%（Typical）, 450 mA ±5%（Maximum）
