Number of pixels

1.3M，1080 x 1280

Light emitter

Light source

High-intensity red LED and blue LED

Aimer

Laser positioning aimer

Focus adjustment

Dual Prime lens

Reading

specifications

Supported

symbol

1D

Code128,GS1 128,Code39,Code93,codabar,2of5 (Industrial 2of5),EAN/UPC

2D

QR、DataMatrix（ECC200）、PDF417、Micro PDF417

Minimum

resolution

1D

3.3mil

2D

5.0mil

I/O

specifications

Control

input

Points

2

Input type

Bidirectional voltage input

Maximum rating

30V

Minimum ON voltage

＜4V

Maximum OFF current

0.001A

Control

output

Points

2

Output type

2 optocoupler output

Maximum rating

30V

Maximum load current

1 output: 50 mA or less, 3-output total: 100 mA or less

Leakage current when OFF

0.1 mA or less

Residual voltage when ON

1 V or less

Ethernet

Supported protocol

TCP Client，TCP Server， Profinet，MELSEC，Ethernet/IP，ModBusTcp(poll/slave)，Fins

Serial

communication

Communication speed

115200/57600/38400/19200/9600 bps

Supported protocol

RS232

USB

Communication

standard

USB 2.0 Full Speed compliant

Environmental

Resistance

Enclosure rating

IP65

Ambient temperature

0° to 50°C

Ambient storage temperature

-20°C to 70°C

Relative humidity

5 to 95% RH (No condensation)

Storage ambient humidity

5 to 95% RH (No condensation)

Ambient light

0 to 10000 lux

Operating environment

No dust or corrosive gas present

Rating

Power supply voltage

10 to 30V DC

Current consumption

0.5 to 1.5 A

Weight

Approx.133±5 g

Dimensions（L x W x H）

55mm x 35mm x 32mm
