Scan mode

Push-button trigger/autosensing/continuous scanning

Communication interface

USB-HID keyboard/USB-COM virtual serial port

Wireless communication distance

Wireless 2.4G: 0-80m (open environment), Bluetooth: 0-20m (open environment).

Prompt way

Buzzer, LED light, vibration motor

How it's set up

Manually scan the setting code one after the other

Housing material

ABS+PC

Cable standards

USB straight line 1m

Exterior dimensions

157mm× 70mm×112mm(product);195mm×105mm×80mm (outer packing)

Weight

198g (net weight), 315g (including packaging accessories).

Performance parameters

Internal storage

500K

Operating frequency band

902~928MHz (can be adjusted according to the requirements of different countries or regions).

The type of card read

ISO 18000-6C (EPC C1G2)

Card reading speed

0.1S

The time of the card reading

<100mS

Reading distance

0-50cm (6C white card).

Sensors

300,000 global CMOS

Resolution

640*480

Light source

White LED

Scan angle

± 60°, ±60°, 360° (elevation, declination, rotation).

Scan rate

120 frames/sec

Field of view

48° (H) x 30° (V)

Print contrast

15% minimum

Decode the kind

1D: EAN- 13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, CodaBar, Code 128, Code93, ITF- 14, ITF-6, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, GS1 Databar(RSS), Code 39, Code 11, MSI-Plessey,etc

2D: QR Code, Data Matrix, PDF417, Micro QR, Aztec, etc, support mobile phone screen code reading

Minimum resolution

1D code 3MIL; QR code 5MIL

Depth of field

QR (20mil)

Data Matrix (10mil)

PDF 417 (7mil)

15~215mm

10~70mm

25~115mm

EAN-13 (13mil)

Code 39 (7mil)

Code 128 (8.3mil)

25~270mm

25~170mm

30~180mm

Electrical parameters

Input voltage

DC 5V±10%

Current

Operating: 350 mA, Standby: 130 mA

Battery

2000mAh lithium-ion battery

Charging time

4 hours

Battery life

10 days (standby), 24 hours (operating: scanning every 5 seconds)

Environmental parameters

Temperature

0°C-50°C(Working); -40°C~+60°C(Storage).

Humidity

5%-95% non-condensing

Ambient brightness

Max.5,000 Lux (fluorescent)

Seismic resistance

It can withstand a 1.5m drop in the air
