Scan mode

Auto-sensing/continuous scanning

Communication interface

USB-HID keyboard, USB-COM virtual serial port, RS232 serial port

Interface type

USB TYPE-B

Prompt mode

Buzzer, LED light

How it is set up

Press the key to set and manually scan the setting code in turn

Housing material

ABS+PC

Cable standard

Straight line 1.3m

Dimension

158 mm×92mm×94mm

Weight

Net weight 335g; Gross weight 345g

Performance parameters

Scan type

CMOS global exposure

Resolution

640*480

Light source

617nm red LED

Scan angle

± 60°, ±54°, 360° (left and right, front and back, turn).

Scan rate

120 times/sec

Field of view

48° (H) x 30° (V)

Printing contrast

Minimum 20%.

Decoding kind

1D: EAN13, EAN 8, UPC-A, UPC-E0, UPC-E1, Code128, Code39, Code93, Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, Code11, CodeBar, MSI, RSS-14, RSS- Ltd, RSS- Exp, Standard 2 of 5, Plessey, ChinaPost 25, GS1 Composite

2D: QR Code, Data Matrix (DM), PDF417, Han Xin, Micro PDF417, Micro QRCode, MaxiCode, Aztec Code, Code16K, support mobile screen reading

Minimum resolution

4thousand

Electrical parameters

Input voltage

DC 5V±10%

Current

Working: 240 mAh; Standby: 190 mAh

Environment parameters

Temperature

0°C-50°C (working); -20°C~+70°C (storage).

Humidity

5%-95% non-condensing
