Scan mode

Push-button trigger/auto-sensing/continuous scanning

Communication interface

USB-HID keyboard/USB-COM virtual serial port/RS232 serial port (optional).

Interface type

USB TYPE-B

Prompt way

Buzzer, LED light, vibration motor

How it's set up

Manually scan the setting code one after the other

Housing material

ABS+PC

Cable standards

Straight line 1.6m

Exterior dimensions

157mm× 70mm×112mm(product);195mm×105mm×80mm(outer packing)

Weight

132.8g (net weight) and 263.5g (including packaging accessories).

Performance parameters

Sensors

300,000 global CMOS

Resolution

640*480

Light source

White LED

Scan angle

± 60°, ±60°, 360° (elevation, declination, rotation).

Scan rate

120 frames/sec

Field of view

48° (H) x 30° (V)

Print contrast

15% minimum

Decode the kind

1D:EAN- 13,EAN-8,UPC-A,UPC-E,ISSN,ISBN,CodaBar,Code 128,Code93,ITF- 14,ITF-6,Interleaved 2 of 5, Industrial 2 of 5,Matrix 2 of 5,GS1 Databar(RSS),Code 39,Code 11,MSI-Plessey,etc

2D: QR Code, Data Matrix, PDF417, Micro QR, Aztec, etc, support mobile phone screen code reading

Minimum resolution

1D code 3MIL;QR code 5MIL

Depth of field

QR(20mil)

QR payment code (mobile phone code)

Data Matrix(10mil)

PDF 417(7mil)

15~160mm

50~320mm

5~110mm

30~125mm

EAN-13(13mil)

Code 39(8mil)

Code 128(7mil)

30~200mm

20~145mm

15~135mm

Electrical parameters

Input voltage

DC 5V±10%

Current

Operating: 350 mA, Standby: 130 mA

Environmental parameters

Temperature

0°C-50°C(Working);-40°C~+60°C(Storage).

Humidity

5%-95% non-condensing

Ambient brightness

Max.5,000 Lux (fluorescent)

Seismic resistance

It can withstand a 1.5m drop in the air
