High-Speed Printing: Capable of speeds up to 127mm/s, with an optional upgrade to 150mm/s.
Versatile Printing Width: A maximum printing width of 104mm for various print formats.
Durable Print Head: Long-lasting print head life of 50km for label paper and 150km for continuous paper.
Advanced Paper Handling: Supports a variety of paper types and widths, with media thickness ranging from 0.06mm to 0.18mm.
Multilingual Support: Out-of-the-box support for most languages, with customization options available.
Barcode Capable: Prints a wide range of 1D and 2D barcodes, with additional options for QRCODE and PDF417.
User-Friendly Design: Easy paper loading structure and manual tearing for simple operation.
Certified Safety Standards: Certified with CCC, CE, and FCC standards for reliable and safe operation.
The BP-2104C features a printing method that is line thermal with a resolution of 203dpi, which is standard and can be upgraded to 300dpi for higher quality prints. It has a RAM of 2MB and flash memory of 2MB for USB versions, and 4MB for Bluetooth versions, ensuring smooth operation and efficient data handling. The printer's command set compatibility includes ESC/POS/OPOS, enhancing its integration capabilities with various software platforms.
This printer has a print head life of 50km for label paper and 150km for continuous paper, indicating its durability. The media characteristics include an easy paper loading structure with automatic feeding, supporting a range of paper types including label paper, continuous paper, black label paper, and fold paper. It can handle paper widths from 38mm to 120mm and media thickness from 0.06mm to 0.18mm. The paper cutting method for this model is manual tearing.
The system support platform includes Windows, Linux, Mac OS for the USB version, and Windows, Android, iOS for the Bluetooth version. It supports most languages out of the box, with the option to customize for additional languages. The printer can handle a variety of barcode types including 1D and 2D barcodes, with QRCODE and PDF417 available as optional features.
The printer operates within a temperature range of 0°C-45°C and a humidity range of 20%-90%, with storage conditions being slightly broader. It is powered by an adapter with a specification of DC 24V 2.5A.
| Printer Characteristics | Printer Name | BP-2104C |
| Printing Method | Line Thermal | |
| Resolution | 203dpi (Optional 300dpi) | |
| Printing Speed | 127mm/s; Optional 150mm/s | |
| Maximum Printing Width | 104mm | |
| Voice/Command Set | ESC/POS/OPOS | |
| Memory | RAM | 2MB |
| Flash Memory | 2MB (Usb Version); 4MB (Bluetooth Version) | |
| Print Head | Print Head Life | 50 Km (Label Paper); 150km (Continuous Paper) |
| Media Characteristics | Loading Method | Easy Paper Loading Structure/Automatic Feeding |
| Paper Type | Label Paper, Continuous Paper, Black Label Paper, Fold Paper | |
| Width | 38mm-120mm | |
| Media Thickness | 0.06mm-0.18mm | |
| Paper Cutting Method | Manual Tearing | |
| Label Width | Minimum 38mm; Maximum 112mm | |
| Label Height | Minimum 30mm; Maximum 250mm | |
| Paper Bin Type | No Built-In Paper Bin (Paper Stand Optional) | |
| Print Function | Automatic Paper Recognition, Intelligent Paper Return And Suction, Reprint For Lacking Paper, Defective Pixel Detection And Other Functions | |
| Operating Parameters | Operating Temperature/Humidity | Temperature: 0°C-45°C Humidity: 20%-90% |
| Storage Temperature/Humidity | Temperature: -10°C-60°C Humidity: 10%-90% (Excluding Paper Rolls) | |
| Electrical Specifications | Adapter | DC 24V 2.5A |
| Physical Parameters | Dimension(L*W*H) | 222*102*96mm |
| Communication Interfaces and Functions | System Support Platform | Usb Version: Windows/Linux/Mac Os Bluetooth Version: Windows/Android/IOS |
| Standard Configuration | USB/USB+Bluetooth (Wifi Can Be Customized) | |
| Fonts/Graphics/Symbols | Support Language | Support Most Languages, Other Languages Need To Be Customized |
| Character Size | ASCII Font a: 12×24 ASCII Font b: 9×17 Chinese Characters: 24×24 | |
| Extended Character Table | Cp437，Cp850，Cp852，Cp860，Cp863，Cp865，Cp866，Wpc1250， Wpc1251，Wpc1252，Wpc1253，Wpc1254 | |
| Barcode Types | 1D | Code 39、39C、I25、Code 93、ITF25、EAN128、Code 128、 Codabar、 EAN-8、EAN8+2、EAN8+5、 EAN-13、EAN13+2、EAN13+5、 UPC-A、UPCA+2、UPCA+5、 UPC-E、UPCE+2、UPCE+5 MSIC、ITF14、EAN14、CODE11、POST |
| 2D | QRCODE、 PDF417 (Optional) | |
| Key Parameters | Key Operation | Power Button (Black Power Button On The Rear Side) Lid Opening Button (Opening Button On Both Sides) Feed Key (Black Feed Key Above) |
| Key Operation Function | 1. Turn Off, Long Press Feed Key And Power Key : Self-Check Page Printing 2. Standby, Long Press Feed Key For 3 Seconds: Enter The Face-Sheet Learning Mode Key Operation Function In 3. Open Lid And Press Feed Key For 10 Seconds: Restore Factory Settings 4. Standby, Short Press Feed Key: Automatically Enter a Blank Sheet 5. During Continuous Printing, Short Press Feed Key: Printing Pauses 6. Pause Printing, Short Press Feed Key: Continue Printing | |
| Indicator Status Description | The Indicator Light Keeps On: Normal Standby Indicator Light Flashes: Buzzer Alarm | |
| Buzzer Alarm Prompt | 1 Beeps: Printer Head Error 2 Beeps: Lacking Paper 3 Sounds: Overheating Error 4 Sounds: Wrong Opening 5 Sounds: Wrong Stitch Mark | |
| Certification Specifications | Agency Certification Standards | CCC, CE, FCC |
