Weight

45 grams

Material

Polycarbonate housing with overmold(PC+TPU)

Communication

Bluetooth HID,SPP,BLE with 30M distance,

Support NFC pairing,RS232 cable(optional)

OS

lOS,Android,Windows,Mac,linux

Battery power

Capacity

550mAh

Standby

>30 days

Charge time

2 hours

Certificate

CE,FCC,IP65,IEC,MSDS,UN38.3

5S

7170

9.9 hours

Scan Engine

N1

Scan mode

Level mode,Pulse mode,Sense mode

Ambient illumination

0~100,000 Lux

Scanner performance

Sensor Type

640×480 CMOS

Light

illumination :White LED;Aiming:625nm Red LED

Scanner Angle

±60°,±60°,±360°(skew,pitch,Roll)

Field of view

Horizontal:42°,Vertical:35.1°

Contrast

≥25%

Barcode Type

1D

Code 128,EAN-13,EAN-8,Code 39,UPC-A,UPC-E,

Codabar,Interleaved 2 of 5,ITF-6,ITF-14,ISBN, Code 93,UCC/EAN-128,GS1 Databar,Matrix 2 of 5, Code 11,Industrial  2 of 5,Standard 2 of 5,Plessey, MSl-Plessey

2D

PDF417、QR Code、Data Matrix

Decoding depth &

Max.Resolution

(1mil=0.0254 mm)

EAN-13

65mm~330mm(13mil)

PDF 417

65mm~110mm(6.67mil)

Code 39

65mm~150mm(5mil)

Data Matrix

50mm~110mm(10mil)

QR Code

45mm~140mm(15mil)

Environmental parameters

Drop resistance

Pass 200 times 1.5m drop test

Temperature

Operating:-15℃ to 60℃

Storage:-20℃ to 60℃

Humidity

<95%(non-condensing)
