Scan mode

Push-button trigger/auto-sensing/continuous scanning

Communication interface

USB-HID keyboard/USB-COM virtual serial port

Wireless communication distance

Wireless 2.4G: 0-80m (open environment).

Prompt way

Buzzer, LED light，Vibration

How it's set up

Manually scan the setting code one after the other

Housing material

ABS+PC

Cable standards

USB straight line 1m

Exterior dimensions

194mm× 98mm×75mm (scanner), 230mm×91mm×67mm (base).

Weight

300 g (scanner), 222.5 g (base).

Performance parameters

Sensors

100W global CMOS

Resolution

1280*720

Light source

White LED

Internal storage

500K

Scan angle

± 60°, ±60°, 360° (elevation, declination, rotation).

Scan rate

120 frames/sec

Field of view

40° (H) x 34° (V)

Print contrast

15% minimum

Decode the kind

1D: EAN13, EAN 8, UPC-A, UPC-E0, UPC-E1, Code128, Code39, Code93, Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, Code11, Coda Bar, MSI, RSS-14, RSS- Ltd, RSS- Exp, Standard 2 of 5, Plessey, etc.

2D: QR Code, Data Matrix, PDF417, Micro QR, Maxi Code, Aztec Code, etc.

Minimum resolution

1D: 3mil; 2D: 5mil

Depth of field

QR (20mil)

Data Matrix (10mil)

PDF 417 (6.7mil)

25~470mm

50~250mm

60~275mm

EAN-13 (13mil)

Code 39 (8.3mil)

Code 128 (8.3mil)

50~700mm

45~420mm

55~480mm

Electrical parameters

Input voltage

DC 5V±10%

Current

Operating: 314 mA, Standby: 151 mA

Battery

2500mAh lithium-ion battery

Charging time

4 hours

Battery life

72 hours (standby), 8 hours (operating: scanning every 5 seconds)

Environmental parameters

Temperature

0°C-50°C(Working); -40°C~+60°C(Storage).

Humidity

5%-95% non-condensing

Ambient brightness

Max.5,000 Lux (fluorescence)

Ingress protection

IP65

Seismic resistance

It can withstand a 1.5m drop in the air
