BX7

Equipped with a new 500,000 global exposure scan engine

Larger scanning window for easier reading

Adjustable angle, flexible and easy to use

Frequently used function buttons, easier to set up

5 styles of prompt sound, soft and bright LED indicator

Rich interface, strong compatibility, support a variety of systems and cash registers


X7(1000)-49
X7(1000)-51
X7(1000)-52
X7(1000)-53
X7(1000)-50
Specification

Physical parameters


Scan mode

Auto-sensing/continuous scanning

Communication interface

USB-HID keyboard, USB-COM virtual serial port, RS232 serial port

Interface type

USB TYPE-B

Prompt mode

Buzzer, LED light

How it is set up

Press the key to set and manually scan the setting code in turn

Housing material

ABS+PC

Cable standard

Straight line 1.35m

Dimension

148mm×97mm×97mm

Weight

Net weight 326g; Gross weight 336g

Performance parameters


Scan type

CMOS global exposure

Resolution

640*480

Light source

617nm red LED

Scan angle

± 60°, ±54°, 360° (left and right, front and back, turn).

Scan rate

120 fps

Field of view

48° (H) x 30° (V)

Printing contrast

Minimum 20%.

Decoding kind

1D: EAN13, EAN 8, UPC-A, UPC-E0, UPC-E1, Code128, Code39, Code93, Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, Code11, CodeBar, MSI, RSS-14, RSS- Ltd, RSS- Exp, Standard 2 of 5, Plessey, ChinaPost 25, GS1 Composite

2D: QR Code, Data Matrix (DM), PDF417, Han Xin, Micro PDF417, Micro QRCode, MaxiCode, Aztec Code, Code16K, support mobile screen reading

Minimum resolution

4thousand

Electrical parameters


Input voltage

DC 5V±10%

Current

Working: 240 mAh; Standby: 190 mAh

Environment parameters


Temperature

0°C-50°C (working); -20°C~+70°C (storage).

Humidity

5%-95% non-condensing
