Physical parameters

Scan mode

Push-button trigger/auto-sensing/continuous scanning

Communication interface

USB-HID keyboard/USB-COM virtual serial port/RS232 serial port (optional).

Interface type

USB TYPE-B

Prompt way

Buzzer, LED light

How it's set up

Manually scan the setting code one after the other

Housing material

ABS+PC

Cable standards

Straight line 1.6m

Exterior dimensions

160mm× 66mm×90mm(product);195mm×105mm×80mm(outer packing)

Weight

171.5 g (net weight) and 256.5g (including packaging accessories).

Performance parameters

Sensors

Global CMOS

Resolution

640*480

Light source

LED

Scan angle

± 60°, ±60°, 360° (elevation, declination, rotation).

Scan rate

120 frames/sec

Field of view

48° (H) x 30° (V)

Print contrast

15% minimum

Decode the kind

1D: EAN13, EAN 8, UPC-A, UPC-E0, UPC-E1, Code128, Code39, Code93, Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, Code11, CodeBar, MSI, RSS-14, RSS- Ltd, RSS- Exp, Standard 2 of 5, Plessey, GS1 Composite

2D: QR Code, Data Matrix (DM), PDF417, Micro QRCode, MaxiCode, Aztec Code, support mobile phone screen reading

Minimum resolution

1D code 4MIL;QR code 10MIL

Depth of field

QR(15mil)

QR payment code (mobile code)

Data Matrix(10mil)

PDF 417(6.7mil)

30~210mm

80~550mm

30- 140mm

50- 120mm

EAN-13(13mil)

Code 39(8mil)

Code 128(15mil)

50~280mm

30- 190mm

80~320mm

Electrical parameters

Input voltage

DC 5V±10%

Current

Operating: 350 mA, Standby: 130 mA

Environmental parameters

Temperature

0°C-50°C(Working);-40°C~+60°C(Storage).

Humidity

5%-95% non-condensing

Ambient brightness

Max.5,000 Lux (fluorescent)

Seismic resistance

It can withstand a 1.5m drop in the air
